Carbon Fiber Tube Sizes

Find the right carbon fiber tube size

Compare outside diameter (OD), inside diameter (ID) and length before choosing a tube. For a round tube, wall thickness = (OD − ID) ÷ 2. Use the catalogue entries below to review an existing size, or send your drawing for a custom requirement.

Selected catalogue sizes

Swipe the table to see all columns →

Outside diameterInside diameterWall thicknessLengthCatalogue entry
30 mm26 mm2 mm1000 mmView 30 × 26 × 1000 mm tube
20 mm18 mm1 mm1000 mmView 20 × 18 × 1000 mm tube
14 mm12 mm1 mm1000 mmView 14 × 12 × 1000 mm tube
12 mm10 mm1 mm1000 mmView 12 × 10 × 1000 mm tube
25 mm23 mm1 mm1000 mmView 25 × 23 × 1000 mm tube
18 mm16 mm1 mm1000 mmView 18 × 16 × 1000 mm tube
18 mm16 mm1 mm500 mmView 18 × 16 × 500 mm tube
18 mm16 mm1 mm250 mmView 18 × 16 × 250 mm tube

These are catalogue examples, not a live stock list. Selected standard products are stocked in California. Confirm the exact size, quantity, shipping origin and lead time with GBTECH before ordering.

Include these details in your enquiry

  • Round, square or other profile
  • OD, ID or wall thickness, and finished length
  • Quantity, tolerance and surface finish
  • Application, loading requirements and delivery location

Choose more than dimensions

Tube construction and fibre direction affect performance. Compare the relevant product series and confirm its specification for your application. Dimensions alone do not establish a load rating.
