Product Series
Carbon fiber fabric
Size Range
Weight 60–800gsm (60/80/100/120/160/200/240/280/300/320/400/480/600/800) | Width 1000mm (Custom available)
Process
Woven | Weave: 2×2 twill / Plain / 4×4 twill (Custom available)
Weave & Finish
Standard carbon fiber fabric | Custom weaves & finishes available
Fiber Tow
1K / 3K / 6K / 12K / 24K available
Available Fiber Grades
T300 / T700 / T800 / T1000 / M40 / M55 / M60
Applications
Sports equipment | Construction | Bridge reinforcement | Marine | Aerospace | Automotive
MOQ & Shipping
MOQ 50m | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom weights, weaves & widths available | Request pricing and lead time
Send weave or orientation, fabric weight (gsm), width, required length, quantity and delivery ZIP code for pricing and availability
Woven Carbon Fiber Plate
Size Range
Thickness 0.2–100mm | Length ≤3000mm (Custom available) | Width ≤1500mm (Custom available) | Standard sizes: 1000×1000mm / 500×600mm / 500×400mm
Process
Hot-pressing | Layer stacking: 0°/90°, ±45°
Weave & Finish
Twill / Plain | Matte / Glossy | Coating: Epoxy / Polyurethane / UV-resistant
Fiber Tow
1K / 3K / 6K / 12K / 24K available
Available Fiber Grades
T300 / T700 / T800 / T1100
Applications
Aerospace | Automotive | Sports equipment | Industrial panels | Structural reinforcement
MOQ & Shipping
MOQ 10 pcs | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom sizes available | Request pricing and lead time
Send thickness, width, length, quantity, finish and delivery ZIP code for pricing and availability
Biaxial Carbon Fiber Fabric
Size Range
Weight 100–800gsm (100/150/200/300/400/600/800) | Width 1270mm (Custom available)
Process
Biaxial weaving | Fiber Orientation: +45°/−45°, 0°/90°, three-axis, four-axis (Custom available)
Weave & Finish
Standard biaxial fabric | Custom orientations available
Fiber Tow
12K / 24K
Available Fiber Grades
T300 / T700 / T800 / T1000 / M40 / M55 / M60
Applications
Sports equipment | Construction | Bridge reinforcement | Marine
MOQ & Shipping
MOQ 50m | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom widths & orientations available | Request pricing and lead time
Send weave or orientation, fabric weight (gsm), width, required length, quantity and delivery ZIP code for pricing and availability
Carbon Fiber Spread Tow Fabric
Size Range
Grid width: 8/10/16/18/20/25mm | Weight: 52–206gsm | Fabric width: 1000mm
Process
Spread tow weaving | Weave: Plain weave
Weave & Finish
Standard spread tow fabric | Smooth surface for ultra-thin laminates
Fiber Tow
12K 24K spread tow (effectively thinner than standard 24K tow)
Available Fiber Grades
T300 / T700 / T800/M30
Grid Width Options (mm)
8 / 10 / 16 / 18 / 20 / 25
Weight Options (gsm)
52 / 83 / 103 / 114 / 130 / 132 / 165 / 183 / 206
Applications
Sports equipment | Construction | Bridge reinforcement | Marine
MOQ & Shipping
MOQ 50m | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom grid widths & weights available | Request pricing and lead time
Send weave or orientation, fabric weight (gsm), width, required length, quantity and delivery ZIP code for pricing and availability
Unidirectional carbon fiber fabric
Size Range
Weight 200–600gsm (200/300/600) | Width 100/150/200/300/500mm (Custom available)
Process
Unidirectional (UD) | Fiber Orientation: 0° (custom orientations available)
Weave & Finish
Non-woven UD fabric | All fibers aligned in single direction | Smooth / Matte finish
Fiber Tow
12K / 24K
Available Fiber Grades
T300 / T700 / T800 / T1000 (Grade 1 = High strength, Grade 2 = Standard)
Applications
Sports equipment | Construction | Bridge reinforcement | Marine
MOQ & Shipping
MOQ 50m | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom widths & weights available | Request pricing and lead time
Send weave or orientation, fabric weight (gsm), width, required length, quantity and delivery ZIP code for pricing and availability
Composite Honeycomb Carbon Fiber Panel
Size Range
Thickness 5–100mm | Length 1000–3000mm (Custom available) | Width 300–1500mm (Custom available)
Process
Hot-pressing | Core materials: Aluminum honeycomb / Polyurethane foam / PVC foam
Weave & Finish
Matte / Glossy | Coating: Epoxy / Polyurethane / UV-resistant
Fiber Tow
1K / 3K / 6K / 12K / 24K available
Available Fiber Grades
T300 / T700 / T800 / T1100
Applications
Aerospace | Automotive | Sports equipment | Industrial panels | Structural reinforcement
MOQ & Shipping
MOQ 10 pcs | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom sizes available | Request pricing and lead time
Send thickness, width, length, quantity, finish and delivery ZIP code for pricing and availability
Colored carbon fiber sheet
Size Range
Thickness 0.2–100mm | Length ≤3000mm (Custom available) | Width ≤1500mm (Custom available)
Process
Hot-pressing | Layer stacking: 0°/90°, ±45°
Weave & Finish
Colored Kevlar / dyed fibers woven for multi-color patterns | Matte / Glossy
Fiber Tow
1K / 3K / 6K / 12K / 24K available
Available Fiber Grades
T300 / T700 / T800 / T1100
Color Options
Red / Blue / Gold / Silver / Green
Applications
Electronic housings | Automotive interiors | Sports gear | Decorative parts
MOQ & Shipping
MOQ 10 pcs | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom sizes available | Request pricing and lead time
Send thickness, width, length, quantity, finish and delivery ZIP code for pricing and availability
Gold and silver thread carbon fiber sheet
Size Range
Thickness 0.2–100mm | Length ≤3000mm (Custom available) | Width ≤1500mm (Custom available)
Process
Hot-pressing | Layer stacking: 0°/90°, ±45°
Weave & Finish
Colored Kevlar / dyed fibers woven for multi-color patterns | Matte / Glossy
Fiber Tow
1K / 3K / 6K / 12K / 24K available
Available Fiber Grades
T300 / T700 / T800 / T1100
Color Options
Gold / Silver
Applications
Electronic housings | Automotive interiors | Sports gear | Decorative parts
MOQ & Shipping
MOQ 10 pcs | Selected sizes stocked in California; confirm availability and lead time
Custom Service
Custom sizes available | Request pricing and lead time
Send thickness, width, length, quantity, finish and delivery ZIP code for pricing and availability
GBTECH
Carbon Fiber Products Manufacturer | GBTECH Factory & R&D Supplier
GBTECH U.S. Sales & Support
Website: www.gbtechmaterials.com
Email: zane@gbtechgroup.cn
Phone: +1 (510) 902-9987
California Warehouse: 38758 Buckboard Common, Fremont, CA 94536, United States
China Manufacturing Headquarters: Building 1, Left Side, Tangye Road, Xinxu, Huiyang, Huizhou, China
Selected standard products are stocked in California. Contact us to confirm availability, shipping origin and lead time for your specifications.
